In order to run the program without problems you need to install slimdx .net end user runtime:
http://slimdx.org/download.php
Install both
2.0 and 4.0 versions
You need to have installed .NET Framework 3.5 or higher
Features
This program have been designed to export the faces models included into the header_### files. The program will create a .cff file which you can import to blender/rhino/3ds max using the scripts provided into the scripts folder of the installation path. You can also export almost all the 3d models included into .rx3 files but most of them will have bugs but a program to do this in the right way is in progress and wil be available soon.
Importing/Exporting
When you create a cff file you can edit it in blender/rhino/3ds max but you can only move vertex you can´t add or delete any vertex or when you try to import a cff file into a rx3 file you will get an error
Scripts
Blender
----------
TO USE CFC FILES INTO BLENDER YOU HAVE TU PUT THE SCRIPTS(.py) PROVIDED INTO ....blender.blenderscripts
-To import a cff file to Blender:
-Go to File MenuImportImportCff and select the .cff file
-THEN ZOOM OUT PUTTING THE CURSOR OVER 3D WINDOW AND MOVING MOUSE WHEEL UNTIL YOU SEE THE FACE
-To export a cff file from Blender:
-Select the scene
-Go to File MenuImportExport cff
Rhino
--------
The scripts have been compiled for rhino 4.0 if you have a previous version the scripts may no run
Scripts Installation:
- Put CFF_ImporterExporter.rhp into scripts folder from your rhino instalation path
- Go to Render menu and select render properties
- In render properties selext plug-ins and click install
- Browse for CFF_ImporterExporter.rhp
- Click Ok and you will see a new menu in your menu bar
